Solar modules
72 high-efficiency single crystal modules Stable output of 36V DC voltage; High conversion rate and high efficiency output; Excellent weak light effect; Adopting high-quality tempered glass with high transmittance; The unique process makes the components beautiful, sturdy, and resistant to wind and snow, making installation convenient; Unique technology to prevent water accumulation, freezing, and deformation within the framework; Can be specially designed according to customer needs and packaged separately; 25 year output power guarantee;
Keywords: solar household system, solar energy system, solar micro-grid power station
72 high-efficiency single crystal modules
Stable output of 36V DC voltage;
High conversion rate and high efficiency output;
Excellent weak light effect;
Adopting high-quality tempered glass with high transmittance;
The unique process makes the components beautiful, sturdy, and resistant to wind and snow, making installation convenient;
Unique technology to prevent water accumulation, freezing, and deformation within the framework;
Can be specially designed according to customer needs and packaged separately;
25 year output power guarantee;
Radiance 1000W/m²
Component temperature 25°C
AM=1.5
SPECIFICATION
| Battery | Single crystal 156 * 156mm (158 * 158mm) |
| Number and arrangement of cells | 72(6×12) |
| Module Size | 1956mm×992mm×35mm |
| Weight | 20.6kg |
| Maximum Power(Pmax) | 350W | 355W | 360W | 365W | 370W | 375W | 380W | 385W | 390W | 395W | 400W |
| Output Power Tolerance | +0~5W | ||||||||||
|
Best Working Current(Imp) Best Working Voltage(Vmp) |
9.11A 38.4V |
9.22A 38.5V |
9.28A 38.8V |
9.41A 38.8V |
9.51A 38.9V |
9.56A 39.2V |
9.64A 39.4V |
9.72A 39.6V |
9.82A 39.7V |
9.88A 40.0V |
9.95A 40.2V |
| Open circuit voltage(Voc) | 45.80V | 46.0V | 46.1V | 46.2V | 46.4V | 46.5V | 46.7V | 46.7V | 46.8V | 46.9V | 47.2V |
| Short circuit current (Isc) | 9.31A | 9.44A | 9.57A | 9.71A | 9.84A | 9.97A | 10.11A | 10.24A | 10.37A | 10.51A | 10.64A |
|
Temperature coefficient of short-circuit current Open Circuit Voltage TCR |
(0.065±0.015)%/°C - (80±10)mV/°C |
||||||||||
| Peak Power TCR | - (0.5±0.05)%/°C | ||||||||||
| NOCT | 47±2°C | ||||||||||
| Operating Temperature | -40℃ to85℃ | ||||||||||
| Maximum System Voltage | 1500VDC |
