Solar modules
166 single crystal high-efficiency module 40V DC voltage stable output High conversion rate and high efficiency output; Excellent low light effect; Adoption of high quality tempered glass with high transmittance; Unique technology to make the components beautiful and sturdy resistance to wind and snow, easy to install; Unique technology to avoid freezing and deformation of water accumulated in the frame; Can be specially designed and individually packaged according to customer requirements; 25-year output power guarantee;
Keywords: solar household system, solar energy system, solar micro-grid power station
166 single crystal high-efficiency module
40V DC voltage stable output
High conversion rate and high efficiency output;
Excellent low light effect;
Adoption of high quality tempered glass with high transmittance;
Unique technology to make the components beautiful and sturdy resistance to wind and snow, easy to install;
Unique technology to avoid freezing and deformation of water accumulated in the frame;
Can be specially designed and individually packaged according to customer requirements;
25-year output power guarantee;
Radiance 1000W/m²
Component temperature 25°C
AM=1.5
SPECIFICATION
| Battery | Monocrystalline 166*33.2(31.8mm) |
| Number and arrangement of cells | 408(68*6) |
| Module Size | 2239*1042*35mm |
| Weight | 24.5kg |
| Maximum Power(Pmax) | 465W | 470W | 475W | 480W |
| Output Power Tolerance | +0~5W | |||
|
Best Working Current(Imp) Best Working Voltage(Vmp) |
12.24A 38.00V |
12.36A 38.02V |
12.50A 38.21V |
12.52A 38.31V |
| Open circuit voltage(Voc) | 46.40V | 46.45V | 46.54V | 46.61V |
| Short circuit current (Isc) | 13.10A | 13.12A | 13.20A | 13.21A |
|
Temperature coefficient of short-circuit current Open Circuit Voltage TCR |
(0.065±0.015)%/°C - (80±10)mV/°C |
|||
| Peak Power TCR | - (0.5±0.05)%/°C | |||
| NOCT | 47±2°C | |||
| Operating Temperature | 40°C to 85°C | |||
| Maximum System Voltage | 1500VDC |
